Plastic Multi Jet Dry Dial Cold Water Meter

Ningbo Haishu Yongzhou Meters Co.,Ltd is a professional water meter manufacturer in China . We are dedicated to producing a wide range of mechanical water meter to meet the needs of our customers. Our products line includes plastic multi jet dry dial cold water meter , brass water meter ,industrial water meter ,as well as water meters . We take pride in delivering water meters of exceptional quality at competitive price to meet the markets .

Model:LXSG-20P

Send Inquiry

Product Description


Yongzhou plastic multi jet dry dial cold water meter is manufactured according to ISO4046 standard . The quality is guaranteed for 5 years warranty . We also offer OEM services to meet the specfic needs of our clients.

Product feature

1.Type name: Plastic multi jet dry dial cold type
2.Model No.: LXSG-20P
3.Standard :ISO 4064 Class B
4.Material: Nylon
5.Feature :Anti-magnet
6.5digits with 4 pointers
7.Dry-dial, Magnetic drive ,Resistance to exterior magnet interference
8.Material: nylon
9.Vacuum sealed register ensures the dial kept free from fog and keep the reading clear in a long term service
10.Measuring accuracy conform to ISO4064 Class B standard
11.Selected high quality & nontoxic plastic(Nano) materials for steady,reliable characteristic and good looking.

Installation requirements:

1.Meter should be installed in horizontal position with the register face upwards
2.Pipe line must be flushed before installation
3.The meter should be constantly full of water during operation
Working Condition

Water temperature:0℃≤t≤50℃ (For cold water meter)
Water pressure: ≤10bar (16bar on request)

Main Technical data

Meter Size  DN (mm) Class
Qs
Overload
Flow
Qp
Nominal
Flow
Qt
Transitional
Flow
Qmin
Min
Flow
Starting
Flow
Min
Reading
Max
Reading
m³/h L/h
15 B 3 1.5 120 30 14 0.0001 99999
20 B 5 2.5 200 50 16 0.0001 99999
25 B 7 3.5 280 70 19 0.0001 99999
32 B 12 6.0 480 120 25 0.0001 99999
40 B 20 10 800 200 56 0.0001 99999
50 B 30 15 3000 450 70 0.0001 99999

Maximum permissible error:

In the lower zone from Qmin inclusive up to but excluding Qt is ±5%
In the upper zone from Qt inclusive up to and including Qs is ±2%

Specifications:

Type size L B H Connection thread
LSXG-15P 15 165 99 104 G3/4B
LXSG-20P 20 190/195 99 106 G1B
LXSG-25P 25 225/260 104 120 G1 1/4B
LXSG-32P 32 230/260 104 120 G1 1/2B
LXSG-40P 40 245/300 120 155 G2B
LXSG-50P 50 280/300 125 155 G2 1/2B

Minimum Order Quantity: 500pcs
Price:
Packaging Details: White box and carton
Delivery Time: 15-30days after receiving deposit
Payment Terms: T/T , L C, West union,etc.
Supply Ability: 50000pcs/month
